Description
Highlights:
- Large camera sensor for sharp images even in low light conditions (4/3 CMOS wide-angle camera)
- Additional zoom camera with 56x hybrid zoom
- long flight time with a realistic 35-45 minutes per battery
- Powerful and yet compact
- incl. 12 months hull insurance in the form of DJI Care Enterprise Basic
Surveying and photogrammetry
How good is the DJI Mavic 3E camera for surveying?
The 4/3-inch sensor with 20 MP is characterised above all by its size and the mechanical shutter . It offers almost twice as much area compared to its predecessor, the DJI Phantom 4 RTK(comparison), which produces significantly better results in low light conditions. This makes it the leader in its class.
How does the RTK work with the DJI Mavic 3E?
The RTK module must be purchased separately for RTK. Once this has been done, simply use the DJI Mavic 3E via a mobile phone network or hotspot with an NTRIP service of your choice (e.g. SAPOS, axio.net or smartnet). The combination with the DJI D-RTK2 Base Station works even more reliably.
Remote control and software
Can I do flight planning with the DJI Mavic 3E as standard?
Yes, the DJI Mavic 3E comes with DJI RC Pro and the flight planning function as standard. Automatic flights for surveying and inspection are possible without third-party software and additional costs.
What is the range of the DJI Mavic 3E remote control?
The range of the remote control is up to 8 km.
In what quality are videos transmitted to the remote control of the DJI Mavic 3E?
The video transmission works in full HD with 1080p and is very reliable.
FAQ
Which app is installed on the DJI Mavic 3E?
The DJI Pilot 2 app is pre-installed and comes as standard with the DJI RC Pro and the DJI Mavic 3E.
Can I download offline maps with the DJI Mavic 3E?
Yes, open the "Profile" menu at the top left of the DJI Pilot 2 app and the option will be displayed.
Does the DJI Mavic 3E have a Local Data Mode? (e.g. for authorities)
Yes, go to the DJI Pilot 2 app at the top left under "Data and Privacy".
How big is a pixel on the DJI Mavic 3E?
3.3µm.
What is the advantage of the mechanical shutter of the DJI Mavic 3E?
A mechanical shutter significantly reduces motion blur, which provides much more accurate results, especially in the survey area.
Characteristics
| Shipping weight: | 5,70 kg |
| Item weight: | 5,70 kg |
| Gewicht: | 915 g |
| Größe: |
221 × 96,3 × 90,3 mm (L × B × H, gefaltet, ohne Propeller) 347,5 × 283 × 107,7 mm (L × B × H, entfaltet, ohne Propeller) |
| Betriebsfrequenz: |
2,400 - 2,483 GHz 5,725 - 5,850 GHz |
| max. Sinkgeschwindigkeit: | 6 m/s |
| max. Aufstiegsgeschwindigkeit: | 8 m/s |
| max. Geschwindigkeit (Windstille, NN): | 21 m/s |
| max. Flughöhe über NN: | 6000 m |
| max. Flugzeit: | 45 min |
| max. Abfluggewicht: | 1.050 g |
| Betriebstemperaturbereich: | -10 °C bis 40 °C |
Scope of delivery
-
1x Mavic 3E aircraft
-
1x Mavic 3 Intelligent Flight Battery
-
1x DJI RC Pro Enterprise
-
3x Mavic 3 Enterprise Propellers (pair)
-
1x USB cable
-
1x USB-C cable
-
1x AC cable for 100W power supply
-
1x DJI USB-C power supply (100W)
-
1x transport case
-
1x screws and tools
