Description
Point cloud registration in the 3Dsurvey Scan module
The 3Dsurvey Scan Module enables fast and precise registration of point clouds from various sources, such as laser scans, drone photogrammetry, or mobile scanners. The point clouds can be aligned automatically via ICP or manually using control points. This allows different data sets to be combined efficiently without external software. Aligning point clouds from different sources is now easy, time-saving, and precise.
X-ray view for CAD drawings in point clouds
With the X-ray view function, the 3Dsurvey Scan module offers a completely new way of working for architects and planners. The transparent display of the point cloud allows you to draw floor plans or sections directly in the 3D view – without having to use external CAD tools. This speeds up documentation and reduces sources of error. If you want to create CAD drawings directly in the point cloud, this module will save you a lot of time.
Efficient processing of scan data in the office
Thanks to the module's internal processing of large point cloud data, projects can be implemented entirely in the office. Even complex building structures can be analyzed and processed without the need for additional on-site measurements. The 3Dsurvey Scan Module optimizes the digital workflow and helps you process point cloud data efficiently in the office, even with large amounts of data.
Key Features
- Intuitive operation Clearly structured interface with logical workflows - ideal for beginners and professionals.
- Automatic point cloud creation Photos or laser scan data are processed fully automatically into precise point clouds.
- Orthophoto generation Georeferenced, true-to-scale orthophotos directly from point clouds or images.
- Digital terrain model (DTM) Automatic terrain extraction without interfering objects - perfect for construction and planning.
- NTv2 transformation Legally compliant coordinate transfer between reference systems.
- Broad data compatibility Flexibly processes UAV, terrestrial, SLAM, or combined data sets.
- Point cloud registration Seamless combination of multiple sources in a single coordinate system.
- Bounding box Live editing of selected point cloud areas - efficient and focused.
- X-ray view for checking complex or hidden structures.
- Volume calculation Fast, precise mass analyses for construction progress and billing.
- CAD vectorization Direct derivation of break lines, contour lines, and contours from point clouds.
- Uniform elevation points Automatic generation of standard-compliant CAD points.
- Profiles & alignments Flexible longitudinal/cross-sectional profiles for infrastructure and construction projects.
- Export & report functions Automated documentation in all common formats (DXF, LAS, PDF, etc.).
Scope of Delivery
Delivery time
Important note: Due to the software provider's licensing procedure, delivery of the license key may take 1 to 2 business days
Scope of delivery
- License key for 3Dsurvey
Are you planning to purchase a larger number of licenses? Please ask about our volume discount
Phone: +49 351 211686
Hardware Requirements
System requirements for 3Dsurvey
3Dsurvey is Windows-based software for processing image data, especially from drone flights. The software uses the processor (CPU) for calculations and the graphics card (GPU) for graphical display. The system requirements vary depending on the project size and processing requirements
The requirements are divided into three usage categories below: minimum requirements, recommended configuration, and professional use with large data sets
Minimum requirements
- Operating system: Windows 7, 8, or 10 (64-bit)
- Processor (CPU): Intel Core i5 or i7
- RAM: 16 GB
- Graphics card (GPU): Nvidia GTX 760 or comparable
- Hard disk space: SSD with at least 128 GB + HDD with at least 500 GB
Recommended system configuration
- Operating system: Windows 10 (64-bit)
- Processor (CPU): Intel Core i7, e.g. Intel Core i7- 6700HQ
- RAM: 16 to 32 GB
- Graphics card (GPU): Nvidia GTX 960 or better
- Hard disk space: SSD with at least 256 GB + HDD with at least 1 TB
Professional use (large projects)
- Operating system: Windows 10 (64-bit)
- Processor (CPU): Intel Core i9, e.g. Intel Core i9-7900X
- RAM: 64 to 128 GB
- Graphics card (GPU): Nvidia GTX 960 or better (RTX series recommended for very large data sets)
- Hard disk space: SSD with at least 512 GB + HDD with at least 1 TB
Additional
- The CPU and RAM performance significantly influence the processing speed.
- A powerful GPU is recommended for displaying large models.
- A fast SSD reduces loading times and speeds up import and export processes.
- 3Dsurvey is only available for Windows. macOS and Linux are not supported.
