Description
3D scan integration for drone surveying
The 3Dsurvey Classroom SCAN module makes automated processing of point clouds and 3D scans a reality. The module allows laser scan data or photogrammetrically generated point clouds to be analyzed and edited directly in the learning environment. Users benefit from a complete 3D process chain, ideal for training in digital surveying with drones and laser scanners.
Smart visualization of point clouds
The integrated visualization component allows 3D models, point clouds, and meshes to be viewed and interpreted directly in the software. This makes it easier to communicate and analyze complex structures. Interactive 3D data analysis is a particular didactic highlight in the classroom, giving learners practical insights into real drone flights.
Compatible with drones and scanner data
The 3Dsurvey Classroom SCAN module is compatible with common drone platforms and terrestrial laser scanners. Data formats such as .las, .laz, and .e57 are supported. This allows real measurement data from DJI drones, Riegl scanners, or even the DJI Zenmuse L2 to be used efficiently in the learning environment. Seamless integration promotes understanding of geodetic workflows with real scan data from practice.
Key Features
-
Intuitive operation
Clearly structured interface with logical workflows - ideal for beginners and professionals. -
Automatic point cloud creation
Photos or laser scan data are processed fully automatically into precise point clouds. -
Orthophoto generation
Georeferenced, true-to-scale orthophotos directly from point clouds or images. -
Digital terrain model (DTM)
Automatic terrain extraction without interfering objects - perfect for construction and planning. -
NTv2 transformation
Legally compliant coordinate transfer between reference systems. -
Broad data compatibility
Flexibly processes UAV, terrestrial, SLAM, or combined data sets. -
Point cloud registration
Seamless combination of multiple sources in a single coordinate system. -
Bounding box
Live editing of selected point cloud areas -
X-ray view
X-ray view for checking complex or hidden structures. -
Volume calculation
Fast, precise mass analyses for construction progress and billing. -
CAD vectorization
Direct derivation of break lines, contour lines, and contours from point clouds. -
Uniform elevation points
Automatic generation of standard-compliant CAD points. -
Profiles & alignments
Flexible longitudinal/cross-sectional profiles for infrastructure and construction projects. -
Export & reporting functions
Automated documentation in all common formats (DXF, LAS, PDF, etc.).
Scope of Delivery
Delivery time
Important note: Due to the software provider's licensing procedure, delivery of the license key may take 1 to 2 business days
Scope of delivery
- License key for 3Dsurvey
Are you planning to purchase a larger number of licenses? Please ask about our volume discount
Phone: +49 351 211686
Hardware Requirements
System requirements for 3Dsurvey
3Dsurvey is Windows-based software for processing image data, especially from drone flights. The software uses the processor (CPU) for calculations and the graphics card (GPU) for graphical display. The system requirements vary depending on the project size and processing requirements
The requirements are divided into three usage categories below: minimum requirements, recommended configuration, and professional use with large data sets
Minimum requirements
- Operating system: Windows 7, 8, or 10 (64-bit)
- Processor (CPU): Intel Core i5 or i7
- RAM: 16 GB
- Graphics card (GPU): Nvidia GTX 760 or comparable
- Hard disk space: SSD with at least 128 GB + HDD with at least 500 GB
Recommended system configuration
- Operating system: Windows 10 (64-bit)
- Processor (CPU): Intel Core i7, e.g. Intel Core i7- 6700HQ
- RAM: 16 to 32 GB
- Graphics card (GPU): Nvidia GTX 960 or better
- Hard disk space: SSD with at least 256 GB + HDD with at least 1 TB
Professional use (large projects)
- Operating system: Windows 10 (64-bit)
- Processor (CPU): Intel Core i9, e.g. Intel Core i9-7900X
- RAM: 64 to 128 GB
- Graphics card (GPU): Nvidia GTX 960 or better (RTX series recommended for very large data sets)
- Hard disk space: SSD with at least 512 GB + HDD with at least 1 TB
Additional
- The CPU and RAM performance significantly influence the processing speed.
- A powerful GPU is recommended for displaying large models.
- A fast SSD reduces loading times and speeds up import and export processes.
- 3Dsurvey is only available for Windows. macOS and Linux are not supported.
Lieferumfang
Lieferzeit
Wichtiger Hinweis: Aufgrund des Lizenzvergabeverfahrens des Softwareanbieters kann die Auslieferung des Lizenzschlüssels 1 bis 2 Werktage in Anspruch nehmen.
Lieferumfang
- Lizenzschlüssel für 3Dsurvey
Sie planen mit einer größeren Anzahl an Lizenzen? Bitte erfragen Sie unseren Mengenrabatt.
Telefon: +49 351 211686
Systemanforderungen
Systemanforderungen für 3Dsurvey
3Dsurvey ist eine Windows-basierte Software zur Verarbeitung von Bilddaten, insbesondere aus Drohnenbefliegungen. Die Software nutzt den Prozessor (CPU) für die Berechnung und die Grafikkarte (GPU) für die grafische Darstellung. Je nach Projektgröße und Anspruch an die Verarbeitung unterscheiden sich die Systemanforderungen.
Im Folgenden sind die Anforderungen in drei Nutzungskategorien unterteilt: Mindestanforderungen, empfohlene Konfiguration und professionelle Anwendung bei großen Datensätzen.
Mindestanforderungen
- Betriebssystem: Windows 7, 8 oder 10 (64 Bit)
- Prozessor (CPU): Intel Core i5 oder i7
- Arbeitsspeicher (RAM): 16 GB
- Grafikkarte (GPU): Nvidia GTX 760 oder vergleichbar
- Festplattenspeicher: SSD mit mindestens 128 GB + HDD mit mindestens 500 GB
Empfohlene Systemkonfiguration
- Betriebssystem: Windows 10 (64 Bit)
- Prozessor (CPU): Intel Core i7, z. B. Intel Core i7-6700HQ
- Arbeitsspeicher (RAM): 16 bis 32 GB
- Grafikkarte (GPU): Nvidia GTX 960 oder besser
- Festplattenspeicher: SSD mit mindestens 256 GB + HDD mit mindestens 1 TB
Professionelle Anwendung (große Projekte)
- Betriebssystem: Windows 10 (64 Bit)
- Prozessor (CPU): Intel Core i9, z. B. Intel Core i9-7900X
- Arbeitsspeicher (RAM): 64 bis 128 GB
- Grafikkarte (GPU): Nvidia GTX 960 oder besser (RTX-Serie empfohlen bei sehr großen Datensätzen)
- Festplattenspeicher: SSD mit mindestens 512 GB + HDD mit mindestens 1 TB
Weitere Hinweise
- Die CPU- und RAM-Leistung beeinflusst die Verarbeitungsgeschwindigkeit maßgeblich.
- Für die Darstellung großer Modelle ist eine leistungsstarke GPU empfehlenswert.
- Eine schnelle SSD verkürzt Ladezeiten und beschleunigt Im- und Exportvorgänge.
- 3Dsurvey ist ausschließlich für Windows verfügbar. macOS und Linux werden nicht unterstützt.
